A versatile lowbay luminaire designed for high efficiency. Available with integral emergency Lithium batteries as standard, additional energy savings can be made when interfaced with smart
controls
Linear LED lowbay
Integral control & dimming options
LED optimised diffuser
IP20
Loop in, loop out connection block
Up to 8 x 2.5mm² terminals
22K, 27K, 3K, 4K, 5K, 65K LEDs
| Part No. | Description | Power (W) | Luminaire Lumens | Ll/cW |
|---|---|---|---|---|
| IMPACT-LIN-72-4K | Linear Lowbay Fitting | 72 | 8530 | 118.5 |
| IMPACT-LIN-144-4K | Linear Lowbay Fitting | 144 | 17,532 | 121.8 |
| IMPACT-LIN-280-4K | Linear Lowbay Fitting | 280 | 34,210 | 122.2 |
| IMPACT-LIN-360-4K | Linear Lowbay Fitting | 360 | 44,023 | 122.3 |
| EM | Integral Emergency |
| EMLFST | Integral Emergency Self Test |
| DD | SwitchDIM/DALI |
| WL | Wireless Control System |
| WLEM | Wireless Monitored Emergency |
| PIR | Programmable PIR |
| DD-PIR | Programmable PIR (DALI / Daylight Harvesting) |
| PIRW | Long Range PIR for Wireless Version |
| BKT | Surface/Trunking Mounting Bracket |
