LED aisle racking and high bay luminaire with a modular, die-cast aluminium heat sink. The energy efficient, high performance LED luminaire for warehouse and factory applications
10 ° Option Available For Wide Aisles
Integral Control Options
IP20 – IP65 Version Available
Universal Mounting Bracket For Surface And Conduit Mounting Available
Range Of Lumen Outputs Available
22K, 27K, 3K, 4K, 5K, 65K LEDs
| Part No. | Description | Power (W) | Luminaire Lumens | Ll/cW |
|---|---|---|---|---|
| STM-75-A-4K | Aisle Racking Luminaire | 75 | 13495 | 177.9 |
| STM-100-A-4K | Aisle Racking Luminaire | 100 | 17165 | 171.2 |
| STM-120-A-4K | Aisle Racking Luminaire | 120 | 20160 | 166.8 |
| STM-200-A-4K | Aisle Racking Luminaire | 200 | 34330 | 171.1 |
| STM-250-A-4K | Aisle Racking Luminaire | 250 | 42000 | 168.0 |
| STM-300-A-4K | Aisle Racking Luminaire | 300 | 51494 | 171.1 |
| STM-350-A-4K | Aisle Racking Luminaire | 350 | 59150 | 168.6 |
| STM-75-HB-4K | High Bay Luminaire | 75 | 13182 | 175.9 |
| STM-100-HB-4K | High Bay Luminaire | 100 | 17414 | 173.9 |
| STM-120-HB-4K | High Bay Luminaire | 120 | 20160 | 167.7 |
| STM-200-HB-4K | High Bay Luminaire | 200 | 34630 | 173.1 |
| STM-250-HB-4K | High Bay Luminaire | 250 | 42750 | 171.0 |
| STM-300-HB-4K | High Bay Luminaire | 300 | 51494 | 171.2 |
| STM-350-HB-4K | High Bay Luminaire | 350 | 58800 | 167.6 |
| EMFL | EM LiFePO4 (4W) |
| EMFLST | EM SELFTEST LiFePO4 (4W) |
| DD | SwitchDIM/DALI |
| MPIR | Manual Set PIR |
| PIR | Remote Programmable PIR |
| DD-PIR | Programmable PIR (DALI / Daylight Harvesting) |
| PIRW | Long Range PIR for Wireless Version |
| IP65 | IP65 Version (Raw Stainless Steel) |
| BKT | Surface/Trunking Mounting Bracket |
| WA | 10° Wide Aisle Option |
| IND | Industrial Driver |
| RM | Remote Box |
