Regor 16

The Regor 16 is a polycarbonate IP65 LED fitting, features side conduit entries and has an eyelid option

Spec sheet

LDT Files

BIM Files

Polycarbonate body
Side and top conduit entries
Security screw option
Integral sensor options
IP65
IK08
22K, 27K, 3K, 4K, 5K, 65K LED Options

Applications

External

Industry

Social Housing

Warehouse

Part No.	Description	Power (W)	Luminaire Lumens	Ll/cW
R16LW48504K	IP65 Circular Bulkhead \| White Body	10	1226	122.6
R16LW48704K	IP65 Circular Bulkhead \| White Body	14	1662	118.7
R16LW48104K	IP65 Circular Bulkhead \| White Body	21	2431	115.8
R16LB48504K	IP65 Circular Bulkhead \| Black Body	10	1226	122.6
R16LB48704K	IP65 Circular Bulkhead \| Black Body	14	1662	118.7
R16LB48104K	IP65 Circular Bulkhead \| Black Body	21	2431	115.8

EMFL	EM LiFePO4 (4W)
EMFLST	EM SELFTEST LiFePO4 (4W)
EMFLP	EM PRO LiFePO4 (4W)
PC	Photocell
MW	On/Off HF Sensor (IR Programmer required)
CF	Corridor Function
DD	SwitchDIM/DALI
EL	Eyelid Attachment
TR	Tamper Resistant Screws
