Urban Round

A die-cast aluminium IP65 fitting. It features side conduit entries and has an eyelid option

Spec sheet

LDT Files

BIM Files

Die-cast aluminium base
Side and top conduit entries
Security screw option
Integral sensor options
IP65 & IK10
22K, 27K, 3K, 4K, 5K, 65K LEDs
Black finish available

Applications

Industry

Office

Retail

Social Housing

Part No.	Description	Power (W)	Luminaire Lumens	Ll/cW
URR-10-4K	Die-cast Aluminium Circular Bulkhead \| White Body	10	1226	122.6
URR-14-4K	Die-cast Aluminium Circular Bulkhead \| White Body	14	1662	118.7
URR-21-4K	Die-cast Aluminium Circular Bulkhead \| White Body	21	2431	115.8
URR-10-BK-4K	Die-cast Aluminium Circular Bulkhead \| Black Body	10	1226	122.6
URR-14-BK-4K	Die-cast Aluminium Circular Bulkhead \| Black Body	14	1662	118.7
URR-21-BK-4K	Die-cast Aluminium Circular Bulkhead \| Black Body	21	2431	115.8

EM	Integral Emergency
EMLFST	Integral Emergency Self Test
PC	Photocell
CF	Corridor Function
MWP	Remote Programmable Microwave
DD	SwitchDIM/DALI
WL	Wireless Control System
WLEM	Wireless Emergency Monitoring
EL	Eyelid Attachment
BK	Black Finish
