The Aspire is a versatile and elegant lighting solution. It features a low-glare design (UGR <16), adjustable colour temperatures, and multiple LED modules for different output levels. Offering high efficiency, TP(a) compliance, and a range of optional extras to suit any specification.
• Flicker free LED panel
• Tridonic control gear
• UGR 16 & TP(A)
• Individual LED lenses
• Steel housing & polycarbonate diffuser
• Loop in, loop out connection block
• Up to 8 x 2.5mm² terminals
• 22K, 27K, 3K, 4K, 5K, 65K LEDs
| Part No. | Description | Power (W) | Luminaire Lumens | Ll/cW |
|---|---|---|---|---|
| ASP-18-4K | Slim Versatile Panel Luminaire | 600 x 600 | 18 | 2580 | 143.0 |
| ASP-27-4K | Slim Versatile Panel Luminaire | 600 x 600 | 27 | 3750 | 138.0 |
| EM | Integral Emergency |
| EMST | Integral Emergency Self Test |
| CF | Corridor Function |
| DD | SwitchDIM/DALI |
| WL | Wireless Control System |
| WLEM | Wireless Monitored Emergency |
