The IP65 Celestial provides a high quality lighting solution for concealed ceilings in clean room applications. Front access as standard with rear entry option available.
Mounting brackets supplied as standard for concealed ceilings
Luminaire suitable for concealed ceilings and for 15mm and 24mm exposed T grid system
IP65 (front face only)
Mounting brackets supplied as standard for concealed ceilings
22K, 27K, 3K, 4K, 5K, 65K LEDs
| Part No. | Description | Power (W) | Luminaire Lumens | Ll/cW |
|---|---|---|---|---|
| UCE-IP-20-55-4K | IP65 Panel Fitting | 500 x 500 | 20 | 2621 | 131.1 |
| UCE-IP-20-4K | IP65 Panel Fitting | 600 x 600 | 20 | 2641 | 132.1 |
| UCE-IP-27-4K | IP65 Panel Fitting | 600 x 600 | 27 | 3458 | 128.1 |
| UCE-IP-20-123-4K | IP65 Panel Fitting | 1200 x 300 | 20 | 2675 | 133.8 |
| UCE-IP-27-123-4K | IP65 Panel Fitting | 1200 x 300 | 27 | 3428 | 127.0 |
| UCE-IP-54-126-4K | IP65 Panel Fitting | 1200 x 600 | 54 | 6743 | 124.9 |
| EM | Integral Emergency |
| EMLFST | Integral Emergency Self Test |
| CF | Corridor Function |
| MWP | Remotely Programmable Microwave |
| DD | SwitchDIM/DALI |
| WL | Wireless Control System |
| WLEM | Wireless Monitored Emergency |
| TPA | TPA Material |
| UGR 19 | UGR 19 |
