Our Panel is a backlit LED fitting with UGR & TP(a) options. It is available in a range of outputs and optional extras.
Flicker free LED panel
Tridonic control gear
Backlit panel
UGR 19 & TP(A)
Individual LED lenses
Steel housing & polycarbonate diffuser
IP20
4K LEDs
| Part No. | Description | Power (W) | Luminaire Lumens | Ll/cW |
|---|---|---|---|---|
| PANEL-22-4K | Backlit Panel Fitting | 600 x 600 | 22 | 2750 | 125.0 |
| PANEL-26-4K | Backlit Panel Fitting | 600 x 600 | 26 | 3200 | 123.0 |
| PANEL-30-4K | Backlit Panel Fitting | 600 x 600 | 30 | 3630 | 121.0 |
| PANEL-36-4K | Backlit Panel Fitting | 600 x 600 | 36 | 4320 | 120.0 |
| PANEL-22-UGR-TPA-4K | Backlit Panel Fitting | UGR 19-TPA | 600 x 600 | 22 | 3100 | 140.9 |
| PANEL-26-UGR-TPA-4K | Backlit Panel Fitting | UGR 19-TPA | 600 x 600 | 26 | 3640 | 140.0 |
| PANEL-30-UGR-TPA-4K | Backlit Panel Fitting | UGR 19-TPA | 600 x 600 | 30 | 4140 | 138.0 |
| PANEL-36-UGR-TPA-4K | Backlit Panel Fitting | UGR 19-TPA | 600 x 600 | 36 | 4860 | 135.0 |
| PANEL-26-UGR-TPA-126-4K | Backlit Panel Fitting | UGR 19-TPA | 1200 x 600 | 26 | 3980 | 142.0 |
| PANEL-36-UGR-TPA-126-4K | Backlit Panel Fitting | UGR 19-TPA | 1200 x 600 | 36 | 5000 | 139.0 |
| PANEL-43-UGR-TPA-126-4K | Backlit Panel Fitting | UGR 19-TPA | 1200 x 600 | 43 | 5890 | 137.0 |
| PANEL-50-UGR-TPA-126-4K | Backlit Panel Fitting | UGR 19-TPA | 1200 x 600 | 50 | 6750 | 135.0 |
| EM | Integral Emergency |
| EMST | Integral Emergency Self Test |
| CF | Corridor Function |
| DD | SwitchDIM/DALI |
